Integrating YuJa Panorama for Digital Accessibility into D2L Brightspace Using LTI 1.3

Avatar
YuJa Product Support
  • Updated

This document provides instructions on integrating the Panorama Platform into your D2L Learning Management System (LMS). If you have any questions regarding any steps in this process, please contact your dedicated Customer Success Manager.

Registering a D2L Application for Panorama

The YuJa Panorama - LMS Connector requires an Application to be registered in order to access the API provided by D2L. To register an Application, follow the instructions below.

  1. Log in as an Admin.
  2. From the top-right corner, click the Gear icon.
  3. Under Security, select Roles and Permissions.
  4. In the Role List, click Administrator.
  5. In the Filter by Tool drop-down menu, select Content, and click Apply Filter.
  6. In the top row, check Organization, Course Template, Course Offering, Group, Semester, Section, and Department.
  7. Click Save.
  8. Repeat steps 5-7 by entering Course Builder, Course Management Console, and External Learning Tools in Filter by Tool.
  9. Next, click the Gear icon in the top-right corner.
  10. Under Organization Related, click Manage Extensibility. 4.png
  11. Ensure the ID Key Authentication tab is selected, and click Register an App. 5.png
  12. Enter a name for Application Name, such as, Panorama.
  13. For Trusted URL, copy and paste the correct URL based on your zone.
    • US Zone: https://panorama-api.yuja.com/d2l-auth
    • CAN Zone: https://panorama-api-cz.yuja.com/d2l-auth
    • EU Zone: https://panorama-api-ez.yuja.com/d2l-auth
  14. Check Enable this application and I accept the Non-commercial Developer Agreement.
  15. Click Register Application.
  16. After registering the Panorama application, you will be redirected to the newly created application. Send the Application ID and Application Key to your Customer Success Manager, and ensure that the application is enabled.
  17. Move to the next section of the guide only once your Customer Success Manager has enabled the required settings

Panorama Configuration for D2L LTI 1.3

Once your Customer Success Manager has successfully enabled the required settings for your institution, you may proceed with installing Panorama for D2L LTI 1.3.

  1. Log in as an Admin.
  2. From the top-right corner, click the Gear icon.
  3. Click Manage Extensibility.
  4. Select the LTI Advantage tab, and then click Register Tool 9.png
  5. Under How would you like to register your tool, select Standard.
  6. Enter a Name for your tool, such as, Panorama LTI 1.3.
  7. Certain fields will require you to enter your zone URL. Refer to your correct zone URL from the list below
    • US Zone: https://panorama-api.yuja.com
    • CAN Zone: https://panorama-api-cz.yuja.com
    • EU Zone: https://panorama-api-ez.yuja.com
  8. Under domain, enter https://<YOUR_ZONE_URL>/lti/lti-app-1.3-entry 10.png
  9. Enter the following URLs for the fields below, and the click Register. 11.png
    • Redirect URLs: https://<YOUR_ZONE_URL>/lti/lti-app-1.3-entry
    • OpenID Connect Login URL: https://<YOUR_ZONE_URL>/lti/lti-app-1.3-oidc-initiation
    • Target Link URL: https://<YOUR_ZONE_URL>/lti/lti-app-1.3-entry
    • Keyset URL: https://<YOUR_ZONE_URL>/lti/lti-app-1.3-jwk
  10. You will be redirected back to the LTI Advantage tab. Locate and click on your newly created tool.  12.png
  11. Scroll down and copy the Brightspace Registration Details. You will need to send this information to your Customer Success Manager in a later step.
  12. Next, Click the Gear icon located in the top-right corner.
  13. Under Organization Related, click External Learning Tools. 14.png
  14. Click the LTI Advantage tab, and click New Deployment. 15.png
  15. Under the Tool drop-down menu, select the LTI tool created earlier.
  16. Add a Name for the Deploy Tool, such as, Panorama. 16.png
  17. Ensure that the following Security Settings are selected.
  18. Under Configuration Settings, check Open as External Resource.  17.png
  19. Click Add Org Units to add courses you would like the LTI App to run on.
  20. Click Create Deployment.
  21. You will be redirected back to the LTI Advantage tab. Click on the newly created tool.  18.1.png
  22. Scroll down and send the Deployment ID along with your Brightspace Registration Details, noted earlier, to your Customer Success Manager.
  23. Click View Links.
  24. Click New Link.
  25. Enter a Name for the link, such as Panorama.
  26. Under URL, enter the URL based on your zone.
    • US Zone: https://panorama-api.yuja.com/lti/lti-app-1.3-entry
    • CAN Zone: https://panorama-api.cz.yuja.com/lti/lti-app-1.3-entry
    • EU Zone: https://panorama-api.ez.yuja.com/lti/lti-app-1.3-entry
  27. Click Save and close.
  28. Once your Customer Success Manager has successfully registered your organization with Panorama, you will be able to proceed with the next section and add Panorama to the Navbar for LTI 1.3.

Adding the Panorama LTI 1.3 Link to the Navbar

Proceed with this section of the guide once Panorama has been successfully integrated into D2L LTI 1.3.

  1. Log in as an Admin or Instructor, and select the course you wish to add the Panorama LTI link to.
  2. Next, click the Actions for Navbar icon and select Edit This Navbar. 22.png
  3. Enter a Name for the Navbar.
  4. Click Add Links.
  5. Click Create Custom Link.
  6. In the Name field, enter Panorama, and then click Insert Quicklink.
  7. Locate and select External Tool from the list of Course Materials.
  8. Use the search bar to search for the Panorama tool.
  9. Click the tool to add it to your custom link.
  10. Set the Behavior to Same window, and click Create to add the Panorama tool to your Navbar.
